POROUS CERAMIC PLATE, 3.0" DIAM., 15 BAR STANDARD
Product Info
Description
Developed from a proprietary mixture of ball clays fired to a ceramic body. Pinkish-tan in color, moderately hard and will withstand pressure differentials of 15 Bar (217.5 psi). Typical bubbling pressure: 220 psi. Effective pore size: 0.16 micron. Hydraulic conductivity: .00000000259 cm/sec. Approximate porosity: 32% by vol. Flow through. All plates are "as cast".
Specs
Diameter: 3.125 inches (tol. +/-0.063"), 7.938 cm (tol. +/-0.160 cm)
Thickness: 0.281 inches (tol. +0.031/-0.016), 0.714 cm (tol. +0.079/-0.041 cm)
Weight: 2.85 oz/81.03 gm
Applications
- Soil Water Retention
- Soil Physics
- Mining
